Digital Multifunctional System
Step Up to a Smarter Workspace
MX-M2651 is All-In-One monochrome MFP with High Productivity, and proven Superb Image Quality, it lets anyone in the office to copy, print, scan, or fax high-quality documents. The MFP becomes highly efficient when it's easily integrated with 3rd party network applications such as Kayleigh and PaperCut with Sharp OSA (Open Systems Architecture).
Quick and Highly Secure, Users can enjoy enterprise-grade features and share information safely on the cloud.
This is the MFP to choose for your business.
This A3 Monochrome MFP won prestigious Buyers Lab (BLI) awards from Keypoint Intelligence
● BLI 2019 Copier MFP Line of the Year Award - New to the Line
● Most Reliable Monochrome Copier MFP 2018-2021
BLI Reliability Award for Most Reliable Monochrome Copier MFP Brand 2018–2021 based on devices tested from January 2012 through May 2018.
| GENERAL (-) | |
| Type | Desktop |
| Engine speed (colour & B/W) | A4 (8 1/2" x 11")*1: Max. 26 ppm, A3 (11" x 17"): Max. 15 ppm, A3W: Max. 14 ppm |
| Control panel display | 10.1-inch colour LCD touchscreen |
| Paper size | Max. A3W (12" x 18"), min. A5 (5 1/2" x 8 1/2"*2) |
| Paper capacity(80 g/m²) | Standard: 650 sheets , Max: 6,300 sheets |
| Paper weight | Tray: 60 g/m2 to 300 g/m2, Multi-bypass tray: 55 g/m2 to 300 g/m2 |
| Warm-up time | 14 sec |
| Memory | Standard: 5 GB (copy/print shared) |
| Power requeirements | Rated local AC voltage ±10%, 50/60 Hz |
| Power consumption | Max. 1.84 kW (220 V to 240 V), max. 1.5 kW (110 V) |
| Dimensions(W×D×H) including document cover | 608 x 650 x 834 mm |
| Weight(approx.) | 64 kg |
| COPIER (-) | |
| Original size | Max. A3 (11" x 17") |
| First copy time | 4.5 sec. |
| Resolution | Scan: 600 x 600 dpi, 600 x 400 dpi Print: 600 x 600 dpi, 9,600 (equivalent) x 600 dpi (depending on copy mode) |
| Continuous copy | Max. 9,999 copies |
| Gradation | Equivalent to 256 levels |
| Zoom range | 25% to 400% (25% to 200% using RSPF) in 1% increments |
| Preset copy rations | Metric: 10 ratios (5R/5E), inch: 8 ratios (4R/4E) |
| NETWORK PRINTER (-) | |
| Memory | - |
| Resolution | 600 x 600 dpi, 9,600 (equivalent) x 600 dpi |
| Interface | USB 2.0 (host, high-speed), 10Base-T/100Base-TX/1000Base-T, wireless LAN (IEEE 802.11 b/g/n) |
| Network protocols | TCP/IP |
| Printing protocols | LPR, Raw TCP (port 9100), POP3 (e-mail printing), HTTP, FTP for downloading print files, IPP, SMB, WSD |
| PDL | Standard: PCL 6 emulation Option: Adobe® PostScript® 3™ |
| Supported OS | Windows Server® 2016, Windows Server® 2019, Windows® 7, Windows® 8.1, Windows® 10 Mac OS 10.9, 10.10, 10.11, 10.12, 10.13, 10.14 |
| Available fonts | 80 fonts for PCL, 139 fonts for Adobe PostScript 3 |
| COLOUR SCANNER (-) | |
| Resolution | - |
| File formats | - |
| Protocols | - |
| Scanner utility | - |
| Network Scanner (-) | |
| Scan method | Push scan (via control panel), Pull scan (TWAIN-compliant application) |
| Scan speed | Colour & B/W: Max. 80 originals/min. |
| Resolution | Push scan: 100, 150, 200, 300, 400, 600 dpi Pull scan: 75, 100, 150, 200, 300, 400, 600 dpi 50 dpi to 9,600 dpi via user setting |
| File formats | TIFF, PDF, PDF/A-1a*10, PDF/A-1b, encrypted PDF, XPS, compact PDF*11*12, JPEG*12, searchable PDF*10, OOXML (pptx, xlsx, docx)*10 |
| Scanner utility | - |
| Scan destinations | Scan to e-mail/desktop*13/FTP server/network folder (SMB)/ USB drive/HDD |
| Document Filing (-) | |
| Document filing capacity | Main and custom folders: 20,000 pages or 3,000 files Quick file folder: 10,000 pages or 1,000 files |
| Stored jobs | Copy, print, scan, fax |
| Storage folders | Quick file folder, main folder, custom folder (max. 1,000 folders) |
| Confidential storage | - |
| B/W Facsimile (-) | |
| Compression method | - |
| Communication protocol | - |
| Transmission time | - |
| Modem speed | - |
| Transmission resolution | - |
| Recording size | - |
| Memory | - |
| Grey scale levels | - |
| Fiery®Print Server (-) | |
| Type | - |
| System software | - |
| Operating system | - |
| CPU | - |
| Memory | - |
| Resolution | - |
| Supported OS | - |
| Network protocols | - |
| Interface | - |
| Printing protocols | - |
| PDL | - |
| Available fonts | - |
| Power requirements | - |
| Power consumption (max.) | - |
| Dimensions (W x D x H) | - |
| Weight (approx.) | - |
