Sharp Big Pad
- Employs a full-flat design with 10-point multi-touch functionality.
- It provides a smooth, quick response for writing and touch gestures, while delivering full HD (1920 x 1080 pixel) resolution.
- The bundled 2 mm-tip touch pen facilities communication by supporting smooth and accurate onscreen writing of fine text and lines.
A Smart New Partner in Innovation
Huddle Spaces
Everyone can engage meaningfully in such small-group meetings by sharing onscreen information. Speedy, productive collaborations become a reality.
Meeting Booths
You can set up a PN-50TC1 in your company’s visitor meeting space to transform your interactions with clients and other visitors.
Meeting Booths
Works in both landscape and portrait orientations. Expands the product’s range of usage to cover a variety of settings.
Maximise the Value of Small Meetings to Achieve a Big Change
| specification (-) | |
| Installation | Landscape / Portrait / Face-up |
| Video Colour System | - |
| Input Terminals | PC analogue: Mini D-sub 15-pin x 1, HDMI x 2 (HDCP and 1080p compatible, PC/AV signal compatible), DisplayPort (HDCP compatible, |
| Output Terminals | 3.5 mm-diameter mini stereo jack x 1 |
| Input/Output Terminals | LAN port (10Base-T/100Base-TX) x 1 |
| Mounting | VESA (4 points), 400 x 200 mm, M6 screw |
| Power Supply | 100V – 240V AC, 50/60 Hz |
| Power Consumption | 105W |
| Dimensions (W x D x H) (approx.) (display only) | 1,151 x 68.5 x 686 mm (45 5/16" x 2 11/16" x 27") |
| Weight (approx.) | 28 kg (61.7 lbs) |
| Main Accessories | Power cord, remote control unit, battery (AAA size) x 2, cable clamp x 3, CD-ROM, SHARP Display Connect license x 1, setup manua |
| LCD Panel (-) | |
| size | 50-inch-class widescreen (49 1/2-inch [125.7 cm] diagonal) TFT LCD |
| Max. Resolution | 1,920 x 1,080 pixels |
| Max. Display Colours (approx.) | 16.77 million colours |
| Pixel Pitch (H x V) | 0.571 x 0.571 mm |
| Max. Brightness (average) | 400 cd/m² |
| Contrast Ratio | 5,000 : 1 |
| Viewing Angle (H/V) | 178°/178° (CR≥10) |
| Active Screen Area (W x H) (approx.) | 1,095.8 x 616.4 mm (43 1/8" x 24 1/4") |
| Response Time | 9.5 ms (grey to grey, avg.) |
| Backlight | LED, edge lit |
| Touchscreen (-) | |
| Touch Technology | Capacitive touch technology |
| PC Connection Port | USB (2.0 compliant) (Type B) x 1 |
| Power Supply | Supplied from main unit |
| Multi Touch | 10 points |
| Protection Glass | Thickness: approx. 3.2 mm Shock resistance: 130 cm |
| Touch Pen (-) | |
| Function Button | - |
| Communication | - |
| Wireless Controller (-) | |
| Wireless Controller | - |
| LAN Terminal | - |
| USB Port | - |
| Wireless Adaptor Port | - |
| Computer Input (-) | |
| Video | Analogue RGB (0.7 Vp-p) [75Ω], HDMI, DisplayPort |
| Synchronisation | Horizontal/vertical separation (TTL: positive/negative) |
| Plug & Play | VESA DDC2B |
| Power Management | VESA DPMS |
| Speaker Output (-) | |
| Built-in | - |
| External | - |
| Environmental Conditions (-) | |
| Operating Temperature | 5˚C to 35˚C |
| Operating Humidity | 20% to 80% RH (no condensation) |
